Wi-Fi-enabled Outdoor Camera & App (Item no. TVAC19100C)
- For flexible outdoor use
- Guided step-by-step installation via app (iOS, Android)
- App access of up to 8 cameras
- HD 720p resolution and infrared night vision function for brilliant image quality
- Professional integrated motion detection (PIR sensor)
- E-mail notification, snapshot function and push notification via app when motion is detected
- Sturdy, weatherproof outdoor camera (IP66)
- Recording to SD card (accessory, max. 32 GB)
- Low network load thanks to compressed data transfer (H.264 compression)
Perfect all-around protection in outdoor areas
This weatherproof WLAN outdoor camera comes with a compatible app for iOS or Android which even technical laymen can use to quickly and easily install the system. With a resolution of 720 p and integrated infrared night vision function, the camera delivers brilliant image quality both day and night.
Event notification and mobile access via app
Movements within the detection range of the camera are reliably identified by the passive infrared sensor. Recording on the SD card starts automatically. If desired, you will be informed of incidents by e-mail or push notification and can take a snapshot or view the corresponding video image data using the app. With the app, you have simultaneous access to the image material of up to eight cameras. The efficient H.264 data compression reduces the network load to a minimum and increases the storage volume.
Note on the product:
This product can only be set up and operated using the app and is not compatible with online access, PC software or recorders.
Technical data:
Item no.: | TVAC19100C |
Dimensions: | 0.44 x 0.22 x 0.16 ft mm |
Number of users: | 3 simultaneous access sessions |
Image sensor: | MP CMOS |
Frame rate: | VGA @ 20 fps / VGA @ 25 fps / 720p @ 5 fps / 720p @ 10 fps fps |
Width: | 0.22 ft mm |
Focal length: | f2.8 mm mm |
Housing material: | Waterproof metal |
Height: | 48 mm |
IR LEDs: | 6 IR Power LEDs |
Length: | 0.44 ft mm |
Max. operating temperature: | 122 °F °C |
Min. operating temperature: | 14 °F °C |
Minimum illumination (color): | 1 - 8 Lux |
Net weight: | 0.3 kg |
Network access: | Ethernet (10/100 Base-T/Base-TX); Wi-Fi (IEEE 802.11 b/g/n) |
Network camera protocols: | TCP/IP, UDP, SMTP, NTP, DHCP, ARP |
PIR range: | 10 ft m |
IP protection class: | 66 |
DC voltage supply: | 5 V |
Power consumption: | 1500 mA |
Encryption: | WPA /WPA2/WPA2-PSK (TKIP, 128 bit AES) |
Video compression: | H.264 |
Scope of delivery:
- 1x Wi-Fi outdoor camera & app
- 1x Power supply unit, 5 V DC/1.5 A
- 1x LAN adapter cable
- 1x Camera mount including mounting material
- 1x Antenna
General Downloads:
Software:
-
Firmware
- Firmware TVAC19100_V1.0.5.0 (v2)
-
Firmware compatible with: TVAC19000, TVAC19100
History
Version: V1.0.5.0
Release date: 05/04/2015
File name: mbootpImage
Note:
Follow the steps below to perform the firmware update:
1. Copy the mbootpImage file onto an empty micro SD card.
2. Disconnect the camera from the mains voltage.
3. Insert the micro SD card into the camera.
4. Connect the camera to a power supply.
5. You must not disconnect the camera from the power supply during the firmware update, as this may result in irreparable damage to the device.
6. Wait for three minutes until the firmware update is complete. Once the update has been successful, the camera will once again register as an access point.
7. The firmware file will be changed to mbootpImage.done. To perform a firmware update on another camera, copy the file onto the micro SD card again and repeat all of the installation steps.
Changes:
1. Firmware to make it easier to install a new camera
2. Improved system stability
3. Timestamp
